Ziroli Turbinator Sport Jet "Short kit"

The Turbinator is an all wood construction sport jet with styling hints from the formative years of jet fighter production in the US It was designed to be a realist turbine trainer. The Turbinator is a great entry level R / C jet, with a large flight performance Envelope, it will fly out and back into short fields that many other jets will not attempt. The design allows the engine to be Hidden with no expensive tail pipe required. The detailed plan set consists of four large sheets which clearly illustrate all the structure as well as showing flap, retract and turbine installation.

• Length : 81 ""
• Weight : 20-22lbs
• Wing loading : 44-48oz / sqft
• Wing area : 1050 sq.in
• Wing span : 72 "
• Wing incidence at root : +2 degrees
• Stab incidence : +3/4 degree
• Dihedral : 1 3/4 "under W11
• Power : 12-18lb thrust turbine
• Washout at wing tip : 2 to 3 degrees built in with jig
• Aileron throws : 7/8 "up and 5/8" down
• Elevator throws : 1 "up and 1" down
• Rudder throws : 1.5 "to right & 1.5" to left
• Flap degrees down : 45-50
• Engine offset degrees : 0 right 2 up
• CG Location : 7 "back from the leading edge of the wing at the fuselage

• Ziroli canopy
• Ziroli plastic wheel Wells
• Engine : 12-18lb thrust turbine
• Fuel tank:: main 64oz rectangle, header 4oz rectangle
• Control Horns : (2) 1/2 ", (5) 1"
• Hinges : (6) DUBRO # 257 LG flat hinges, (15) Robart LG hinge points
• Covering : film or 1oz fiberglass cloth and epoxy resin
• Retracts Main
• Retracts nose
• Retract Air Kit
• Wheels Main : 3 "
• Wheel nose : 2.5 "
• Wheels tail : 2.25 "
• Radio channels : 6 or more
• Servos : Flaps (2) 150+ oz MGBB, Ailerons (2) 90+ oz BB, Elevators (2) 90+ oz BB, Rudder (1) 90+ oz BB, nose wheel (1) 60+ oz BB, Gear ( 1) 50oz,

MG- metal gear BB- ball bearing
